SoilRipper™ Tillage Points Extra High Strength Steel

Maximum soil fracturing with reduced draft load

Ingersoll’s new SoilRipper™ tillage points feature a robust design and superior fine grain chromium-carbide steel to withstand the most challenging soil conditions, providing the best overall value choice.

SoilRipper™ - This image depicts the Diameter, Thickness, Concavity, and Edge Type of the blades

Features

  • Patented design
  • More robust design with extra high strength steel for longer service life
  • Wing and nose surface geometry generates maximum soil fracturing while reducing draft loads
  • As they wear, SoilRipper points maintain their ability to penetrate the toughest soil conditions
  • Wear feature protects mounting hardware
  • Ideal for high speed compaction-busting tillage applications
SoilRipper™

Specifications

  • Solid one-piece cast for extreme durability with super hard steel
  • Formed from fine grain chromium-carbide steel
  • Rockwell harness score of 48-50 Rc
  • 7.5” winged SoilRipper point designed for a 1.25” shank width
  • 24 lbs.
  • Designed to fit Case IH, DMI, Krause and John Deere equipment
